CONTROL RELAY 10A 4 POLE 24V CS7-31E-24Z SPRECHER & SCHUH

Description

The Sprecher + Schuh CS7-31E-24Z industrial control relay is rated for 10 AMPS continuous duty (25 AMP general purpose), has 3 normally open (N.O.) and 1 normally closed (N.C.) power poles and comes with a 24v50/60Hz AC rated coil. This 4 pole relay has screw terminals and can be mounted on standard 35MM Din rail or screw-fixed to the back of a panel. Up to 4 additional auxiliaries can be added to the CS7-31E-24Z via two pole side mounted or four pole top mounted auxiliaries, for a maximum of 8 contacts per unit.
