LED DRIVER DIMMABLE 24V 300W 100-277VAC OT-24300-TDWJ

Model: OT-24300-TDWJ

SKU: 3963

In Stock

Description

Cooling by free air convection
High efficiency: up to 88% & Min.Load 10% only
Suitable for LED lighting and moving sign applications
Full protection aluminum housing for dry / damp locations
Match with TRIAC, electronic low voltage, magnetic low voltage dimmers
PWM output (Pulse-Width Modulation) output, does not change the colour index
Flicker-free, compatible with Forward phase, Reverse phase, TRIAC, MLV, ELV Dimmers
Work for 110-277V AC input, 120V & 277V dimmers, allows for flicker free dimming down to 1%

Input Voltage	110-277V AC
Output Voltage	24V DC
Maximum Wattage	300W
Amps	12.5A
Dimmable	Yes
Frequency Range	47-63Hz
Power Factor	0.99 at 120V AC 0.97 at 277V AC
Efficiency (Typ.)	88%
AC Current (Max.)	3.4A at 110V AC
Short Circuit	Shut down o/p voltage; Repower on to recover after fault condition is removed
Over Loading	120%
Operating Temperature	-40ºC ~ +60ºC
Operating Humidity	20-90% RH, non-condensing
Safety Standards	UL 8750
Withstand Resistance	I/P-O/P: 1880V AC
Isolation Resistance	I/P-O/P: 100MΩ / 500V DC / +25ºC / 70% RH
Warranty	5 years
Case Quantities	10
