Black Dimmer Class A Votatec (BAK-004AG)

Description

Model No.: BAK-004AG
About 60 Gr
UI-1472 Solid Dimmer Switch
Rated working Power: 600W
Rated working voltage: 120V 60Hz
Insulation Resistance: >10MΩ (DC500V)
Withstand Voltage: 1500 (AC)
Mechanical Life: 40,000 times (one reciprocating time for each switch)
Rubber shell fire rating: UL94-V2
Creepage distance: ≥3mm
Electrical clearance: 1.2mm between live parts & 3mm
between live parts & other parts
Cable Specification: 18AWG
Working Temperature: -20°C~60°C
Option : Class A ( compatible with most lights)

Specification	Details
Model No.	BAK-004AG
Standard	UL1472
Rated Power	600W Incandescent / 150W CFL & LED
Rated Voltage	120V / 60Hz
Insulation Resistance	>10MΩ (DC500V)
Mechanical Life	40,000 times
Cable Specification	18 AWG
Operating Temperature	-20°C ~ 60°C
Option	Class A
Type	3-Way
Electrical Clearance	1.2 mm (between live parts) & 3 mm (between live and other parts)
Creepage Distance	≥3 mm

Brand	VOTATEC
